Water Aeration System AQUAFORCE AQ-AERO1252-F117Q3
AQUAFORCE AQ-AERO1252-F117Q3 is a high-capacity professional automated pressure aeration system designed for efficient removal of iron, manganese, and hydrogen sulfide.
How It Works
The process consists of three main stages:
- Column No. 1 (Aeration and Degassing): Water is actively mixed with air supplied by a compressor. This performs two functions:
- Oxidation: Oxygen converts dissolved iron into solid form (sediment).
- Gas Removal: Gases and hydrogen sulfide are stripped from the water. Excess air along with accumulated gases is automatically vented out through a special air release valve at the top of the column.
- Column No. 2 (Filtration): Water enters the second column containing catalytic media, which finalizes the oxidation and traps iron particles. Thanks to the increased column size (1252), the system handles higher loads stably, providing clear, clean water at the outlet.
- Backwash (Self-Cleaning): When it's time to rinse (based on a timer or water volume), the system automatically starts regeneration. Iron particles accumulated in the second column are washed out by a reverse water flow and discharged into the drain.
Application
Ideal for large households and properties with high water demand. Its capacity allows for a comfortable supply of clean water to 3-4 simultaneous taps.
Kit Components
- Two filter housings 1252: Large-volume composite columns for heavy-duty performance.
- Control Valve Runxin F117Q3 (3/4"): Intelligent regeneration based on both timer and water usage.
- Pulse Meter (3/4"): For precise tracking of the system’s capacity.
- Powerful AS19 Compressor: High-performance model that ensures effective oxidation without restricting your pump's flow rate.
- Aeration Head (1"): A unit for mixing water with air.
- Air and Gas Release Valve: Automatically removes waste air and hydrogen sulfide.
- Compressor Control Relay: Ensures the compressor runs only during water usage (programmable).
- Filter Media: Birm (Made in USA) — 50 liters, plus 10 liters of quartz sand and gravel support bed.
Our Advantages (Why AQUAFORCE?)
- Smart Resource Management: Unlike many competitors, our control valve allows setting backwash simultaneously by days and by volume (capacity). This ensures timely cleaning while saving water and electricity, and significantly extends the lifespan of the filter media.
- High-Performance Compressor: We equip the system with a more powerful compressor. This allows the system to work more efficiently and, most importantly, does not restrict your pump's flow rate, allowing it to deliver water at full capacity.
- Eco-friendly: Operates without salt or chemical reagents. Purification is achieved using only atmospheric oxygen.
Technical Specifications
- Flow Rate: up to 2.0 - 2.2 m3/h.
- Filter Media: Birm (manufactured in USA).
- Minimum Inlet Pressure: 2.2 bar.
- Working Pressure: up to 5 - 6 bar.
- Media Volume: 43 L (catalytic) + 10 L (support bed).
- Column Size: 1252 (diameter 30 cm, height 132 cm).
