AQUAFORCE AQ-AERO1465-F116Q3

Water Aeration System AQUAFORCE AQ-AERO1465-F116Q3

AQUAFORCE AQ-AERO1465-F116Q3 is an industrial-capacity automated pressure aeration system designed for the efficient removal of high concentrations of iron, manganese, and hydrogen sulfide.

How It Works

1. Column No. 1 (Aeration and Degassing): Water is mixed with air to oxidize iron and strip away gases. Excess air and gases are automatically vented through the release valve.
2. Column No. 2 (Filtration): Water passes through the catalytic media where iron is trapped. The massive 1465 column size ensures stability even under heavy loads.
3. Backwash (Self-Cleaning): When it's time to rinse (by volume or timer), the system automatically flushes accumulated particles into the drain.

Application

Designed for large properties: estates, hotels, apartment buildings, or industrial facilities. It comfortably supplies clean water to 5-6 simultaneous taps.

Kit Components

• Two filter housings 1465: Heavy-duty composite columns.
• Control Valve Runxin F116Q3 (1"): High-flow intelligent controller.
• Pulse Meter (1"): For precise flow tracking in high-demand systems.
• Powerful AS19 Compressor: High-performance model that ensures effective oxidation without limiting your pump's flow rate.
• Air and Gas Release Valve: Automatically removes waste gases.
• Filter Media: Birm (Made in USA) — 72 liters, plus 15 liters of quartz sand and gravel support bed.

Our Advantages

• Smart Resource Management: Backwash settings based on both days and volume save water while significantly extending the life of the media.
• Unrestricted Power: Our more powerful compressor allows your pump to work at full capacity, ensuring maximum flow.
• Eco-Friendly: Chemical-free purification using only atmospheric oxygen.

Technical Specifications

• Flow Rate: up to 3.0 - 3.5 m3/h.
• Filter Media: Birm (manufactured in USA).
• Media Volume: 72 L (catalytic) + 15 L (support bed).
• Minimum Inlet Pressure: 2.5 bar.
• Column Size: 1465 (diameter 36 cm, height 166 cm).
