AQUAPHOR AP-UF-1000
Ultrafiltration System
The AQUAPHOR AP-UF-1000 is an advanced modular, automatic ultrafiltration station designed to deliver sterile, high-quality water for industrial and commercial applications. Thanks to its sophisticated hollow fiber membranes, the system ensures stable and reliable purification even under fluctuating raw water conditions.
Function and Key Advantages
The AP-UF-1000 system acts as an ultimate barrier against a wide range of microbiological and mechanical contaminants. It removes particles as small as 0.01 micron, effectively eliminating:
- Bacteria (99.9999%) and viruses (99.99%).
- Suspended solids, parasites, and turbidity.
- Monovalent and divalent ions (within the ultrafiltration scope).
This purification capability allows the production of ultra-pure water without the need for chemical bactericides.
Operation and Technology
- Fully Automatic: Operation is managed via a Smart Controller, ensuring user-friendly operation and maintaining an electronic log of system activity.
- Membrane Longevity: The system features integrated Automatic Backwash and Chemicals Enhanced Backwash (CEB) functions, which significantly extend the lifespan of the membranes and overall equipment.
- Low Cost of Ownership: With low energy consumption (\text{0.017 kWh}) and a compact design, the system provides low operation costs.
- Rapid Deployment: Its "Plug&Play" design ensures quick installation and start-up.
- Integration: The system seamlessly integrates with standard AQUAPHOR PROFESSIONAL equipment.
Applications
The compact and reliable AP-UF-1000 is an ideal choice for a variety of demanding applications:
- Pretreatment for Reverse Osmosis (RO) systems.
- Whole-house filtration.
- Laboratories.
- Food and beverage production.
AQUAPHOR AP-UF-1000 Technical Specifications
- Model: AP-UF 1000
- Filtration Grade: Less than 0.01 micron
- Permeate Capacity: 1000 liters per hour
- Power Consumption: 0.017 kWh
- Dimensions (L x W x H): 800x 500 x1600 mm.
- Inlet Connection: 3/4 inch, female thread.
- Outlet Connection: 3/4 inch, female thread.
- Drain Connection: 1/2 inch.
- Power Supply: 220 Volt
