AQUAFORCE HoReCa RO 230 L/H

High-Performance AQUAFORCE HoReCa RO 230 L/H

 Reverse Osmosis System for Restaurants

General Description

The reverse osmosis system with a 230 liters per hour output is a professional solution designed to meet the needs of restaurants, cafes, bars, and other food service establishments. It ensures a stable supply of perfectly pure water, a key ingredient for preparing beverages and dishes, and guarantees the flawless operation of expensive equipment. The system is designed to fill a storage tank and can operate continuously for up to 3 hours

Purification Stages and Key Specifications

The system operates on the principle of reverse osmosis, providing the maximum level of water purification. The filtration process includes several stages:

1. Preliminary Mechanical Filtration: Removes large particles (sand, rust, silt) to protect the membrane.
2. Carbon Filtration: Effectively eliminates chlorine, organochlorine compounds, organic substances, and unpleasant odors, protecting the reverse osmosis membrane from damage.
3. Two Reverse Osmosis Membranes: The heart of the system. Water is forced under pressure through two membranes in parallel, which trap up to 99.8% of all dissolved impurities, including hardness salts, heavy metals, bacteria, and viruses.
4. Post-Filtration: A final carbon filter-conditioner that improves the taste of the water before it is delivered to the user.

Technical Data:

• Output: 230 L/h , or 3.6 to 3.9 L per minute. The output speed depends on the water temperature and inlet pressure.
• Duration of Continuous Operation: No more than 3 hours.
• Degree of Purification: Up to 99.8% of all types of contaminants.
• Inlet Working Pressure: Not less than 1.8 bar and not more than 4.5 bar. If the pressure is below the minimum, a booster pump is required; if above the maximum, a pressure reducer is needed.
• Design: Compact for easy placement.
• Automation: Fully automatic operation and control.

Advantages for Your Business

• Protection and Savings: The most significant benefit is the complete absence of scale. The system protects your expensive equipment: coffee machines, combi steamers, dishwashers, boilers, and ice makers. This significantly reduces maintenance and repair costs, as well as saves electricity.
• Flawless Quality: Pure water is the foundation of perfect taste. Coffee, tea, and dishes prepared with this water gain a rich, clean flavor without any foreign aftertastes. Ice becomes crystal clear, does not get cloudy, and does not melt too quickly.
• Perfectly Clean Dishes: After washing in a dishwasher using reverse osmosis water, no white spots or streaks are left on glasses, plates, and cutlery. This improves the aesthetics of presentation and reduces the time spent on manual polishing.
• Increased Efficiency: A reliable and automated system guarantees a constant supply of clean water, allowing staff to focus on customer service rather than on equipment issues.

• Specifications

  Membrane 2	Membrane 800G-3213 FOR RO SYSTEMS
  Brand	AQUAFORCE
  System type	Direct flow
  Usage	HOUSEHOLD
  Pure water flow L /min	3,6-3,9 l/min
  Drain water flow/min	0,9-1,2 l/min
  Filtration levels	4
  Max without interruptions in work	3 hours
  Prefilter cartridges size	BB 10'' PP+CARBONE
  Weight,kg (brutto)	17,20
  Bracket type	STABLE PRESSURE
  Membrane 2	Membrane 800G-3213 FOR RO SYSTEMS
  Product size W x L x H, mm	450x240x690
  Voltage,V	24V
  Weight,kg (netto)	15,60
  Packing size W x L x H, mm	460x240x730
